  1. #46
    Join Date
    5th December 2009 - 14:56
    Bike
    800XC
    Location
    Christchurch
    Posts
    750
    Quote Originally Posted by pete-blen View Post
    I fucked up
    Isn't that "the mother of all inventions" (or was that necessity)...... whatever I reckon you are on the right track


    (or 2 or 3 )

  2. #47
    Join Date
    1st May 2011 - 12:35
    Bike
    XT660R / TTR250 / 2 old Montesa's
    Location
    Blenheim.. now ChCh
    Posts
    1,803
    Quote Originally Posted by Crim View Post
    Isn't that "the mother of all inventions" (or was that necessity)...... whatever I reckon you are on the right track


    (or 2 or 3 )
    Sorted I hope....
    I now know how I fucked up....
    Done the numbers for a reduced trail front
    end that gives a longer wheel base.. But
    when I desided to stay with the standard
    front end... I didn't redo the numbers...

    Heres the adjustable fuck up repair...
    Of course it was alway part of the design...
    Attached Thumbnails Attached Thumbnails Click image for larger version.

Name:	SSA41628.jpg
Views:	38
Size:	287.0 KB
ID:	248851

  3. #48
    Join Date
    26th October 2002 - 07:56
    Bike
    Designa Yello 2004 DR 650
    Location
    Wanaka, New Zealand, New
    Posts
    1,146
    Quote Originally Posted by pete-blen View Post
    Heres the adjustable fuck up repair...
    ...its not a fuckup till it CAN'T be fixed. ... its new and improved!!
    Cheers Andi & Ellen
    twomotokiwis.com
    Two Moto Kiwis Adventure Ride, May 3rd 2012 -> 20XX Prudhoe Bay Alaska -> Ushuaia Argentina -> Then Wherever We Point The Bars

  4. #49
    Join Date
    27th April 2008 - 21:37
    Bike
    94 & 98 BMW GS1100
    Location
    Palmerston North
    Posts
    320
    You mean you are supposed to use numbers when you are working on a project
    Thats mine screwed then
    GSers

  5. #50
    Join Date
    23rd April 2004 - 19:16
    Bike
    2010 DC Skate Shoes
    Location
    Roxby Downs, SA
    Posts
    7,089
    The guy I stay with in San Remo (just off of Phillip Island) is well known off-road side car endurance racer. This setup has won a number of 24hr endurance races, with a race distance of 750km it's a well proven rig!
    Click image for larger version.

Name:	IMG_7825.jpg
Views:	41
Size:	198.5 KB
ID:	248929Click image for larger version.

Name:	IMG_7826.jpg
Views:	41
Size:	184.2 KB
ID:	248930Click image for larger version.

Name:	IMG_7827.jpg
Views:	45
Size:	184.6 KB
ID:	248931
    KiwiBitcher
    where opinion holds more weight than fact.

    It's better to not pass and know that you could have than to pass and find out that you can't. Wait for the straight.

  6. #51
    Join Date
    26th September 2005 - 21:14
    Bike
    05 450 EXC, 990 S
    Location
    Christchurch
    Posts
    3,642
    Quote Originally Posted by R6_kid View Post
    The guy I stay with in San Remo (just off of Phillip Island) is well known off-road side car endurance racer. This setup has won a number of 24hr endurance races, with a race distance of 750km it's a well proven rig!
    Click image for larger version.

Name:	IMG_7825.jpg
Views:	41
Size:	198.5 KB
ID:	248929Click image for larger version.

Name:	IMG_7826.jpg
Views:	41
Size:	184.2 KB
ID:	248930Click image for larger version.

Name:	IMG_7827.jpg
Views:	45
Size:	184.6 KB
ID:	248931
    Looks like that thing has very little of the XR600 left appart from a tank and seat. Is that a complete custom frame? So many questions that I don't need to know the answer too and don't have time to ask.

    One comment though - screw standing on the side of that for 750km!!! "Shuffle up a bit mate so I can sit on the back of the seat for a bit!"

    Cheers R
    "The ultimate result of shielding men from the effects of folly is to fill the world with fools." - Herbert Spencer, English Philosopher (1820-1903)

  7. #52
    Join Date
    1st May 2011 - 12:35
    Bike
    XT660R / TTR250 / 2 old Montesa's
    Location
    Blenheim.. now ChCh
    Posts
    1,803
    Ok.. Its rideable this time..
    its a learnt skill.... if yer stuff
    up yer run out of road real fast..
    there a few grass verges in the
    Taylor Pass with un-planed
    wheel tracks in them..
    Attached Thumbnails Attached Thumbnails Click image for larger version.

Name:	SSA41633.jpg
Views:	31
Size:	390.1 KB
ID:	249115   Click image for larger version.

Name:	SSA41632.jpg
Views:	35
Size:	406.0 KB
ID:	249117

  8. #53
    Join Date
    22nd March 2007 - 10:20
    Bike
    2015 HD Street 500
    Location
    Blenheim
    Posts
    2,178
    Been watching this build with interest,
    Could you see this same set up being used on a road bike with success?
    I see the end product so far as being appealing to the eye.
    Some good kiw buiding skills there.
    To be old and wise, first you must be young and stupid.

  9. #54
    Join Date
    1st May 2011 - 12:35
    Bike
    XT660R / TTR250 / 2 old Montesa's
    Location
    Blenheim.. now ChCh
    Posts
    1,803
    Quote Originally Posted by Subike View Post
    Been watching this build with interest,
    Could you see this same set up being used on a road bike with success?
    I see the end product so far as being appealing to the eye.
    Some good kiw buiding skills there.
    For sure....
    the leaning is great.. l you don't no the cars there till
    yer run out of lean.. mine only has 15* either way..
    For some reason right turns are a prob.. not sure if its
    me or the set up.. once the lean limiter reachs the end
    then yer have to lean off the bike & turn the bars...
    35 years of pre progamming that yer keep the bars stright
    when turning is a hard habbit to brake... I did notice that on
    gravel you can also make slight corrections with the thottle..
    I would say give the bike a lot more lean than I have..And
    keep the side car wheel lead to NO more than 15% of the
    bikes wheel base... The other point is to reduce the trail
    in the front end to lighten the steering... but mines not
    heavy... maybe being a light g bike to start with helped ?..

    to reduce the trail.. yer move the front wheel foward till
    the axle is above the point where the rake angle would
    intersect with the ground..

  10. #55
    Join Date
    19th December 2010 - 21:02
    Bike
    2010 Bike Moto Mk2
    Location
    Takaka
    Posts
    129
    good job done
    sidecars have potential for all sorts of uses

    Photobucket

  11. #56
    Join Date
    19th December 2010 - 21:02
    Bike
    2010 Bike Moto Mk2
    Location
    Takaka
    Posts
    129
    ...you can put something to eat in them...or a mate...or something


    Photobucket

  12. #57
    Join Date
    1st May 2011 - 12:35
    Bike
    XT660R / TTR250 / 2 old Montesa's
    Location
    Blenheim.. now ChCh
    Posts
    1,803

    completed

    At last it works
    On the road yer hardly know the car is there..
    Only time it makes its self known is tight corners
    to fast as yer run out of lean then it requires you to
    shift weigh to the inside... normal riding its just lean as normal..
    It can travel at 80/90kph quite saftely..On tighter sealed roads
    you just have to be aware of its limits....
    Gravel roads are where the fun is.... No worrys about the bike
    slideing out from under yer... Don't need to pick clear lines of gravel..
    It needs more power, the few times I have got it to slide
    On rougher tracks , The car is quite happy to go up/down over bumps
    & holes with NO movement of the bike...
    Even the brakeing it still straight , no pull to the left...

    I think.... I,m really going to have to get a bigger bike 600/650
    and build a Darka style unit...
    Attached Thumbnails Attached Thumbnails Click image for larger version.

Name:	SSA41663.jpg
Views:	25
Size:	338.1 KB
ID:	250097   Click image for larger version.

Name:	SSA41664.jpg
Views:	25
Size:	365.8 KB
ID:	250098   Click image for larger version.

Name:	SSA41670.jpg
Views:	26
Size:	352.9 KB
ID:	250099   Click image for larger version.

Name:	SSA41671.jpg
Views:	23
Size:	303.1 KB
ID:	250100   Click image for larger version.

Name:	SSA41666.jpg
Views:	26
Size:	270.8 KB
ID:	250101
    Pete

    90% of all Harleys built are still on the road... The other 10% made it back home...
    Ducati... Makeing riders into mechaincs since 1964...

  13. #58
    Join Date
    2nd March 2004 - 13:00
    Bike
    FransAlp 700
    Location
    Nelson
    Posts
    14,484
    Before long you'll be looking for a 2nd hand v-rod engine

  14. #59
    Join Date
    2nd March 2004 - 13:00
    Bike
    FransAlp 700
    Location
    Nelson
    Posts
    14,484
    A front mudguard on backwards? You philistine!
    That's almost as bad as using a KTM rear guard as a headlight surround on a CB400!

    How tough is that rear mount? It' going to cop a hammering over the triples.

    Wonder how a DR650 would go with one of them hanging off the side?

  15. #60
    Join Date
    1st May 2011 - 12:35
    Bike
    XT660R / TTR250 / 2 old Montesa's
    Location
    Blenheim.. now ChCh
    Posts
    1,803
    Quote Originally Posted by NordieBoy View Post
    A front mudguard on backwards? You philistine!
    That's almost as bad as using a KTM rear guard as a headlight surround on a CB400!

    How tough is that rear mount? It' going to cop a hammering over the triples.

    Wonder how a DR650 would go with one of them hanging off the side?

    guard mount ?... not bad but it could benifit from a brace...
    Car mount ? ... The bar under the bike is 20mm solid stainless
    with 3/4" cromoly rod ends....

    It took a hideing up MT Pat...

    Would be great on a 650.... Heres one in the making......
    http://www.advrider.com/forums/showt...ght=DR650+hack


    PS.... the mudguards one of those new fang-dangle bi-directional jobs...
    Pete

    90% of all Harleys built are still on the road... The other 10% made it back home...
    Ducati... Makeing riders into mechaincs since 1964...
